High Precision 1 Axis Turntable DT200-C with 15kg Payload Capacity Designed for Inertial Navigation Testing and Angular Measurement

Name: High Precision 1 Axis Turntable DT200-C with 15kg Payload Capacity Designed for Inertial Navigation Testing and Angular Measurement
Brand: Jiujiang RUYA Precision Technology Co., Ltd
SKU: DT200-C
Availability: InStock

Brand Name:	RUYA
Model Number:	DT200-C
MOQ:	1 set
Price:	negotiable
Delivery Time:	2-3 months
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001

Load Weight:

15KG

Table Flatness:

0.02mm

Table Runout:

0.02mm

Rotary Accuracy:

±3″

Positioning Error:

±3″

Positioning Repeatability:

±2″

Rate Range:

±0.0001°/s~±200°/s

Rate Resolution:

0.0001°/s

Packaging Details:

wooden box

Supply Ability:

≤3 sets，3 months

Highlight:

15kg inertial navigation test turntable

DT200-C inertial navigation test turntable

Single Axis inertial navigation turntable

Product Description

DT200-C Payload 15kg Single Axis Inertial Navigation Test Turntable

Product Overview

The DT200-C Payload 15kg Single-axis Inertial Navigation Test Turntable is designed for calibration and testing applications requiring precise angular measurements. This system features a turntable base that mounts securely to vertical steel piping with adjustable height positioning capability.

The turntable system includes both hardware components and comprehensive control software compatible with W7 and later versions. The software provides automated computer control, data acquisition, processing, and display functionality, allowing users to configure operating modes, control parameters, speed settings, and acceleration protection thresholds.

Technical Specifications

Specification	Value
Load Weight	15Kg
Table Diameter	Ф200mm
Table Flatness	0.02mm
Table Runout	0.02mm
Rotary Accuracy Of Axis	±3″
Positioning Error Of Angular Position	±3″
Positioning Repeatability Of Angular Position	±2″
Rate Range	±0.0001°/s~±200°/s
Rate Resolution	0.0001°/s
Rate Accuracy	ω≤1°/s: 2×10⁻³ (1° average) 1°/s≤ω<10°/s: 2×10⁻⁴ (10° average) ω≥10°/s: 2×10⁻⁵ (360° average)
Maximum Angular Acceleration	≥100°/s²
User Slip Ring	Customizable

Product Images
