Articulated Arm Coordinate Measuring Machine
Created with Pixso. RUYA RA515 High Precision Articulated Arm Coordinate Measuring Machine with 0.035mm Accuracy and 1.5m Measurement Range

RUYA RA515 High Precision Articulated Arm Coordinate Measuring Machine with 0.035mm Accuracy and 1.5m Measurement Range

Brand Name: RUYA
Model Number: RA515
MOQ: 1 pc
Price: negotiable
Delivery Time: 5-10 working days
Payment Terms: T/T
Detail Information
Place of Origin:
China
Certification:
ISO 9001
Accuracy:
0.035mm
Repeatability:
0.025mm
Packaging Details:
Flight case + Wooden box
Supply Ability:
1-10 pieces,2 weeks
Highlight:

Portable 3D Measuring Arm

,

High Precision Coordinate Measuring Machine

,

Portable CMM Coordinate Measuring Machine

Product Description
RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm
Product Overview
RUYA RA515 High Precision Articulated Arm Coordinate Measuring Machine with 0.035mm Accuracy and 1.5m Measurement Range 0
Instrument Composition:
  • Fixed platform
  • Magnetic stand (or suction cup, tripod)
  • Measuring machine host
  • Computer and software
  • Measuring head assembly
During measurement operations, the system must be stably fixed on the platform (leveling is not required, but the relative position between the measuring machine and workpiece must remain stable throughout the entire measurement process). The main unit is secured using suction cups or screws, with the portable computer connected via USB signal cable. The software handles acquisition and processing of measurement data along with generation of comprehensive measurement reports.
Measurement Capabilities
Geometric Feature Detection
  • Measure geometric features on workpieces and generate new features through projection and intersection of existing geometric elements
  • Rapid analysis of spatial dimensions including distances and angles between geometric features
  • Custom coordinate system creation using points, lines, and surfaces with linear dimension marking capabilities
GD&T Geometric Tolerance Detection
The measurement software provides comprehensive GD&T tools for evaluating form and position tolerances of geometric features, including verticality, parallelism, flatness, cylindricity, coaxiality, inclination, position, and more.
3D Model to Actual Object Comparison
Software compatibility with multiple 3D data formats and various coordinate alignment methods enables automatic comparison of measured geometric features and surface point data with theoretical values from 3D models, providing detailed error analysis graphical reports.
Test Reporting
Quick output of test reports in PDF, Excel, and MHT formats. Powerful inspection report customization functionality delivers convenient, fast reporting with comprehensive text and graphical documentation.
Application Fields
Automobile production lines, aerospace, shipbuilding, inspection fixture manufacturing, mold manufacturing, and related industrial applications.
Product Specifications
Model Spatial Measurement Range Space-length Indication Error Uniaxial Coordinate Measurement Consistency
RA515 1.5m 0.035mm 0.025mm
RA520 2.0m 0.045mm 0.032mm
RA525 2.5m 0.060mm 0.035mm
RA530 3.0m 0.080mm 0.056mm
RA535 3.5m 0.100mm 0.071mm
Optional Accessories
RUYA RA515 High Precision Articulated Arm Coordinate Measuring Machine with 0.035mm Accuracy and 1.5m Measurement Range 1
