Precision Angle Measuring Metal Multi Faceted Prism

Name: Precision Angle Measuring Metal Multi Faceted Prism
Brand: Jiujiang RUYA Precision Technology Co., Ltd
SKU: DLT-8，DLT-12，DLT-17，DLT-23，DLT-24，DLT-36
Availability: InStock

Brand Name:	RUYA
Model Number:	DLT-8，DLT-12，DLT-17，DLT-23，DLT-24，DLT-36
MOQ:	1 pc
Price:	negotiable
Delivery Time:	20-30 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001

Accuracy:

Grade 0, Grade 1

Working Surface Roughness Ra:

≤0.025

Packaging Details:

Wooden box

Supply Ability:

1-10 piece， 4-6 weeks

Highlight:

Precision Angle Measuring multi faceted prism

Metal multi faceted prism

DLT-8 multi faceted prism

Product Description

Precision Angle Measuring Metal Multi Faceted Prism

Product Description

Metal multi-faceted prism is a high-precision standard instrument, which is mainly used to verify the indexing error of optical indexing head, indexing table, goniometer and other circular indexing instruments, and can also be used as an angle positioning reference in high-precision machining or measurement.

It is divided into two kinds of even and odd planes, the working angle of the former is the integer degree, it is used to verify the large periodic error of the shafting system of the circular indexing instrument, and can also be used for diameter measurement; And the working angle of the latter is a non-integer degree, which can comprehensively verify the large period of the shafting system of the circular indexing instrument and the small period error of the micrometer, and can correctly determine the uncertainty of the circular indexing instrument.

Product parameters

Product	Model	Accuracy	Working Angle Manufacturing Error	Circumcircle Diameter	Working Face Flatness	Perpendicularity Between Working Face And Positioning Face	Working Surface Roughness Ra
Octahedron	DLT-8	grade 0	±1”	φ80mm	0.03μm	5"	≤0.025
		grade 1	±2”		0.05μm	10"
Dodecahedral prism	DLT-12	grade 0	±1”	Φ100mm	0.03μm	5"	≤0.025
		grade 1	±2”		0.05μm	10"
17 hedral prism	DLT-17	grade 0	±1”	Φ100mm	0.03μm	5"	≤0.025
		grade 1	±2”		0.05μm	10"
23 hedral prism	DLT-23	grade 0	±1”	Φ120mm	0.03μm	5"	≤0.025
		grade 1	±2”		0.05μm	10"
24 hedral prism	DLT-24	grade 0	±1”	Φ120mm	0.03μm	5”	≤0.025
		grade 1	±2”		0.05μm	10"
36 hedral prism	DLT-36	grade 0	±1”	Φ150mm	0.03μm	5”	≤0.025
		grade 1	±2”		0.05μm	10"
