ZDFT-360A Program Controlled Automatic Multi Tooth Indexing Table with 30kg Load Capacity

Brand Name: RUYA
Model Number: ZDFT-360A
MOQ: 1 pc
Price: negotiable
Delivery Time: 20-30 working days
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO 9001
Load (kg):
30
Weight (kg):
45
Table Diameter (mm):
Φ205
Dimensions (mm):
368x138x362
Packaging Details:
wooden box
Supply Ability:
1-10 pcs, 4-6 weeks
Highlight:

Indexing Table Automatic

,

Indexing Table Multi Tooth

,

ZDFT-360A indexing turntable

Product Description
ZDFT-360A Program Controlled Automatic Multi Tooth Indexing Table
Product Overview

The ZDFT-360A Program-controlled Automatic Multi-tooth Indexing Table consists of a multi-tooth indexing table and a set of segmented drum wheel reading systems, achieving the highest resolution of angle readings up to 0.1" on both fixed and movable reading sleeves. This system is suitable for measurement sites where continuous readings are required.

The program-controlled multi-tooth indexing table is operated by a computer-controlled stepper motor that manages the lifting and rotation of the upper tooth disc. This enables the multi-tooth indexing table to be controlled via programming for automated testing applications.

Technical Specifications
Model ZDFT-360A
Table diameter (mm) Φ205
Dimensions (mm) 368*138*362
Accuracy - Vertical use 0.5"
Accuracy - Horizontal use 1"
Angle Measuring Repeatability Accuracy 0.2"
Load (kg) 30
Weight (kg) 45
Product Images
ZDFT-360A Program Controlled Automatic Multi Tooth Indexing Table with 30kg Load Capacity 0 ZDFT-360A Program Controlled Automatic Multi Tooth Indexing Table with 30kg Load Capacity 1
